EQUIPPED WITH:
AIR LINE F/R/L
SAFETY HOODED FOOT PEDAL
SPEED CONTROL VALVE
REAR ADJUST RAM STROKE CONTROL AND MANUAL BACK GAUGE
LOWER DIE HOLDER
STEEL 90 DEGREE TOP PUNCH AND 3/4 in VEE DIE
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
Floor Stand, Part No. BST500 ------------- $ 810.00
Optional Gauging:
Standard Gauge SBG - Basic Rear Mounted and Adjusted Manual Back Gauge (must specify model number of press) -------------------- $695
Rear Adjusted Pro-Gage PG24568 - Pro-Gage Micrometer Back Gauge, 0 – 4” Precision Dial Travel, (2) Units on (1) Common Crossbar --- $1,780
Front Mounted Pro-Gage: PG1224 - (1) Pro-Gage Micrometer Front Gauge with (4) Axis Mounting System, (bed T-rail not included) ------- $1,170
PGTR - Bed Mounted T-Rail, Must Specify Length Needed. Price Shown is Per. Foot and Add $35 Cut Fee ---- $80
Front Operated Rear Gauge with DRO: FABGDRO - Front Adjust Back Gauge w/Handwheel, DRO & Twin Ball Screws, Range: 12T – 18”, 24/42T – 21 “ -- $2,690
FABGEXT - Required Extension Kit When Workpiece Support Table is used With Front Adjust Back Gauge-------- $110
Smart-Gage CNC Back Gauge: SG12 - Smart-Gage (1) Axis Programable Back Gauge System for 12 Ton Press Brakes, Quick Clamp Flip Fingers. Stores up to 99 Jobs, 9 Bends per Job, 12 Inch Range, 500 IPM & Retract Delay Feature -- $8,480
SG2442 - Smart-Gage (1) Axis Programable Back Gauge System for 24/42 Ton Press Brakes, Quick Clamp Flip Fingers. Stores up to 99 Jobs, 9 Bends per Job, 12 Inch Range, 500 IPM & Retract Delay Feature -- $8,800
Optional Stroke Stop:
Front Adjust Stroke Stop: YDRO Digital Readout Addition to Standard Rear Adjust Y-Axis Ram Stroke Control--------------------------------- $780
YFADRO Convenient Front Adjust Y-Axis Ram Stroke Stop with DRO for Repeatable Stop Settings ----------------- $1,430
Optional Safety Equipment:
Two Hand Control SA2 Two Hand Safety Control with Front Workpiece Support Table, 2 Ft. ------------------------------------------------------------ $2,230
SA4 Two Hand Safety Control with Front Workpiece Support Table, 4 Ft. ------------------------------------------------------------ $2,330
SA5 Two Hand Safety Control with Front Workpiece Support Table, 5 Ft. ------------------------------------------------------------ $2,430
SA6 Two Hand Safety Control with Front Workpiece Support Table, 6 Ft. ------------------------------------------------------------ $2,540
SA8 Two Hand Safety Control with (2) 4 Ft. Front Workpiece Support Table, 8 Ft. Total Width -------------------------------- $2,940
SA10 Two Hand Safety Control with (2) 5 Ft. Front Workpiece Support Table, 10 Ft. Total Width ------------------------------ $3,150
NEW→ Physical Barrier Guarding, ( L. R. & Rear )
PBG2 Barrier Guards for Left, Right, and Rear of Machine with Access Doors under Lock and Key, 2 Ft. ----------------------- $3,700
PBG4 Barrier Guards for Left, Right, and Rear of Machine with Access Doors under Lock and Key, 4 Ft. ----------------------- $3,780
PBG5 Barrier Guards for Left, Right, and Rear of Machine with Access Doors under Lock and Key, 5 Ft. ----------------------- $3,850
PBG6 Barrier Guards for Left, Right, and Rear of Machine with Access Doors under Lock and Key, 6 Ft. ----------------------- $3,860
PBG8 Barrier Guards for Left, Right, and Rear of Machine with Access Doors under Lock and Key, 8 Ft. ----------------------- $3,950
PBG10 Barrier Guards for Left, Right, and Rear of Machine with Access Doors under Lock and Key, 10 Ft. --------------------- $4,010
NEW→ Safety Mat System, ( Front )
SMS28 System for 2 Ft. Machine, Includes: 3’ x 8’ Mat, SA2, Operators Control Pedestal & Dual Safety Valve Interface. --- $9,890
SMS410 System for 4 Ft. Machine, Includes: 3’ x 10’ Mat, SA2, Operators Control Pedestal & Dual Safety Valve Interface. -- $10,430
SMS511 System for 5 Ft. Machine, Includes: 3’ x 11’ Mat, SA2, Operators Control Pedestal & Dual Safety Valve Interface. -- $10,710
SMS612 System for 6 Ft. Machine, Includes: 3’ x 12’ Mat, SA2, Operators Control Pedestal & Dual Safety Valve Interface. -- $10,970
SMS814 System for 8 Ft. Machine, Includes: 3’ x 14’ Mat, SA2, Operators Control Pedestal & Dual Safety Valve Interface. -- $11,520
SMS1016 System for 10 Ft. Machine, Includes: 3’ x 16’ Mat, SA2, Operators Control Pedestal & Dual Safety Valve Interface.- $12,070
Optional Workpiece Assist Equipment:
Workpiece Support Table WT200 Workpiece Support Table for 2 Ft. Machine. (1) Fully Adjustable Table, 2 Ft. Wide x 1 Ft. Deep. ------------------------ $520
WT400 Workpiece Support Table for 4 Ft. Machine. (1) Fully Adjustable Table, 4 Ft. Wide x 1 Ft. Deep. ------------------------ $620
WT500 Workpiece Support Table for 5 Ft. Machine. (1) Fully Adjustable Table, 5 Ft. Wide x 1 Ft. Deep. ------------------------ $720
WT600 Workpiece Support Table for 6 Ft. Machine. (1) Fully Adjustable Table, 6 Ft. Wide x 1 Ft. Deep. ------------------------ $820
WT800 Workpiece Support Table for 8 Ft. Machine. (2) Fully Adjustable 4 Ft. Wide Tables Side by Side x 1 Ft. Deep Ea. --- $1,240
WT1000 Workpiece Support Table for 10 Ft. Machine. (2) Fully Adjustable 5 Ft. Wide Tables Side by Side x 1 Ft. Deep Ea. -- $1,440
Large Sheet Support, ( for use with WT )
LSSWT Sheet Support Attachment for WT. (2) Adjustable 2 x 18 Inch Extensions, Clamps to the Underside of Any WT. --- $630
Large Sheet Support, ( for use without WT )
LSS200 Large Sheet Support. (2) Fully Adjustable 3 x 30 Inch Units & 2 Ft. Bed Rail, 0 to 2 Ft. L. to R. Spread, Full. ----------- $720
LSS200 Large Sheet Support. (2) Fully Adjustable 3 x 30 Inch Units & 4 Ft. Bed Rail, 0 to 4 Ft. L. to R. Spread, Full. ----------- $820
LSS200 Large Sheet Support. (2) Fully Adjustable 3 x 30 Inch Units & 5 Ft. Bed Rail, 0 to 5 Ft. L. to R. Spread, Full. ----------- $925
LSS200 Large Sheet Support. (2) Fully Adjustable 3 x 30 Inch Units & 6 Ft. Bed Rail, 0 to 6 Ft. L. to R. Spread, Full. ----------- $1,040
LSS200 Large Sheet Support. (2) Fully Adjustable 3 x 30 Inch Units & 8 Ft. Bed Rail, 0 to 10 Ft. L. to R. Spread, Full. --------- $1,140
LSS200 Large Sheet Support. (2) Fully Adjustable 3 x 30 Inch Units & 10 Ft. Bed Rail, 0 to 10 Ft. L. to R. Spread, Full. ------- $1,240
Optional Punch Clamping Equipment:
Segmented Safety Clamp Ram
CR2 Segmented Safety Clamp Ram for 2 Ft. (4) Individual Clamp Segments, Accepts Safety Tang or Std. Punches. ------ $1,340
CR4 Segmented Safety Clamp Ram for 4 Ft. (8) Individual Clamp Segments, Accepts Safety Tang or Std. Punches. ------ $1,860
CR5 Segmented Safety Clamp Ram for 5 Ft. (10) Individual Clamp Segments, Accepts Safety Tang or Std. Punches. ----- $2,170
CR6 Segmented Safety Clamp Ram for 6 Ft. (12) Individual Clamp Segments, Accepts Safety Tang or Std. Punches. ---- $2,590
CR8 Segmented Safety Clamp Ram for 8 Ft. (16) Individual Clamp Segments, Accepts Safety Tang or Std. Punches. ---- $2,900
CR10 Segmented Safety Clamp Ram for 10 Ft. (20) Individual Clamp Segments, Accepts Safety Tang or Std. Punches. --- $3,420
Optional Increased Tooling Space:
SH* Additional Tooling Space for Deep Box Forming. * 2, 4, 6 or Any Inch Increase over Standard Tooling Space. -------- $P.O.R.
Atek Press Brake Tooling:
Part No.           Description                                   Angle      Nose Radius     Vee    Net Height  Thick     Lbs./Ft.                            Price Per. Inch
90P100 ------- 90⁰ Punch --------------------------- 90⁰ ------ 1/64’’--------------- 3-3/4’’ ------ 1’’ ------- 13 ------------------------ $ 9
90D375 ------- 90⁰ x 3/8’’ Vee Die ---------------- 90⁰ ------------------ 3/8’’ --- 1-3/4’’ ------ 1’’ ------- 6 ------------------------- $7
90D500 ------- 90⁰ x 1/2’’ Vee Die ---------------- 90⁰ ------------------ 1/2’’ --- 1-3/4’’ ------ 1’’-------- 6 ------------------------- $7
90D625 ------- 90⁰ x 5/8’’ Vee Die ---------------- 90⁰ ------------------ 5/8’’ --- 1-3/4’’ ------ 1’’-------- 9 ------------------------- $7
90D750 ------- 90⁰ x 3/4’’Vee Die ----------------- 90⁰ ------------------ 3/4’’ --- 1-3/4’’ --- 1-1/2’’ ---- 9 ------------------------- $8
90D100 ------- 90⁰ x 1’’ Vee Die ------------------- 90⁰ ------------------- 1’’ ---- 1-3/4’' --- 1-1/2’’ ---- 8 ------------------------- $8
85P150 ------- 85⁰ Punch --------------------------- 85⁰ ------ 1/8’’ --------------- 3-3/4’’ --- 1-1/2’’ ---- 17 ------------------------ $17
85D150 ------- 85⁰ x 1-1/2’’ Vee Die -------------- 85⁰ ----------------- 1-1/2’’ -- 2-1/4’’ ------ 2’’ ------- 18 ------------------------ $18
85D200 ------- 85⁰ x 2’’ Vee Die ------------------- 85⁰ -------------------- 2’’ ---- 2-1/4’’ --- 2-1/2’’ ---- 20 ------------------------ $26
90GP375 ----- 90⁰ x 18 ga. Gooseneck Punch - 90⁰ ------ 1/64’’--------------- 3-3/4’’ --- 1-1/2’’ ---- 11 --------------------------- $14
90GP625 ----- 90⁰ x 14 ga. Gooseneck Punch - 90⁰ ------ 1/32’’--------------- 3-3/4’’ --- 1-1/2’’ ---- 11 --------------------------- $14
30P100 ------- 28⁰ Accute Punch ------------------ 30⁰ ------ 1/32’’--------------- 3-3/4’’ ------ 1’’ ------- 11 ------------------------ $14
30D375 ------- 30⁰ x 3/8’’ Vee Die ----------------- 30⁰ ------------------ 3/8’’ --- 1-3/4’’ ------ 1’’ ------- 6 ------------------------- $12
30D500 ------- 30⁰ x 1/2’’ Vee Die ----------------- 30⁰ ------------------ 1/2’’ --- 1-3/4’’ ------ 1’’ ------- 6 ------------------------- $12
30P125 ------- 28⁰ Accute Punch ------------------ 28⁰ ----- 3/64’’--------------- 3-3/4’’ --- 1-1/4’’ ---- 11 ------------------------- $15
30D625 ------- 30⁰ x 5/8’’ Vee Accute Die ------ 30⁰ ------------------ 5/8’’ --- 2-1/8’’ --- 1-1/2’’ ---- 9 ----------------------------- $10
30P150 ------- 30⁰ Accute Punch ----------------- 30⁰ ----- 1/16’’--------------- 3-3/4’’ --- 1-1/2’’ ---- 12 -------------------------- $13
30D100 ------- 34⁰ x 1’’ Vee Accute Die --------- 34⁰ -------------------- 1’’ ---- 2-3/4’’ ------ 2’’ ------- 14 ------------------------ $14
FP137 --------- Flattening Punch ------------------- 0⁰ ------------------------------ 2-5/8’’ --- 1-3/8’’ ---- 14 ------------------------ $16
FD137 --------- Flattening Die ------------------- 0⁰ ------------------------------ 2-5/8’’ --- 1-3/8’’ ---- 14 -------------------------- $16
* Add $35 Cut Charge to Each Tool
* Add $90 Square End Milling Charge to Each Tool (if desired)
DELIVERY:
SUBJECT TO STOCK
