SPECIFICATIONS:
CAPACITY ---------------------------- 11 in ROUND AT 90°
                                                           17 in FLAT AT 90°
                                                           11 in ROUND AT 45°
                                                           11 in FLAT AT 45°
CAPACITY-------------------------- 6 inch W x 9 inch H AT 60°
                                                       6 inch SQUARE AT 6°
                                                       7 inch wide x 2 inch thick - Flat Stock at 60°
                                                       6 inch pipe (6-7/8 inch O.D.) at 60°
BLADE SPEEDS ------------------------ 70-135-250 FPM
BLADE SIZE -------------------------- 12 ft X 1 in X .035
HEAD PRESSURE ----------------------- HYDRAULIC CYLINDER
VISE -------------------------------- QUICK ADJUSTING
SHUT OFF ---------------------------- AUTOMATIC
MOTOR ------------------------------- 1-1/2 H.P. 220 VOLT, SINGLE PHASE
SHIPPING WEIGHT --------------------- 800 LBS.
SIZE - TABLE HEIGHT ----------------- 28-1/8 in
LENGTH ----------------------- 72 in
WIDTH ------------------------ 34-1/4 in
HEIGHT ----------------------- 47 in
SEALED OIL BATH WORM GEAR ----------- STANDARD
REMOVABLE CHIP TRAY ----------------- STANDARD
CONSTRUCTION ------------------------ HEAVY STEEL, WELDED AND MACHINED FOR ACCURACY AND DURABILITY - 14 SEALED PRECISION BALL BEARINGS
FEATURES:
*HEAD MOVES LEFT OR RIGHT FOR ANGLE CUTTING
*BUILT-IN PROTRACTOR FOR FAST AND ACCURATE SELECTION OF ANGLES
*STOCK REMAINS IN ONE POSITION FOR ALL CUTS
*CAPACITY TO CUT 17 in FLAT AT 90°
*CAPACITY TO CUT 11 in ROUND AT 90°
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
* Stock gauge with micro-adjuster...........................................................................................................................$125.00
* 5 ft. Stock support stand with 4 rollers .................................................................................................................$800.00
* Single stock support stand with one roller, movable.............................................................................................$325.00
* Air System (cleans and cools blade) ....................................................................................................................$325.00
DELIVERY:
SUBJECT TO STOCK
