FEATURES:
● Universal tooling set included with each machine
● Forged roll shafts precision ground and fitted for maximum performance and minimal deflection
● Roll shafts supported with conical steel bearings on each side of A Frame
● Heavy duty structure and rigid components for high section modulus ratings
● Reinforced engineered mainframe design proven to outperform competitive models
● In-line direct drive roll shaft system 3-roll driven
● Threaded roll shafts with micrometric flange adjustment helps eliminate spacer usage
● Touchpad controls with digital center roll positioning
● Control tower with low voltage controls and foot pedal
● Hydraulic machine with memory storage has eight (8) individual programs and unlimited passes
● Patented by Ercolina, simultaneous downfeed and roll movement minimizes deformation
● Optional anti-twist correction system required for angle iron “Leg In” applications
EQUIPPED WITH:
● 50mm roll shaft diameter
● Maximum pipe capacity 2-1/2″ Sch. 40
● Maximum angle capacity 2-1/2″ x 2-1/2″ x 1/4″
● Bending speeds 20% faster than competitive machines
● Universal tooling set included with each machine – 7″ OD
● Forged roll shafts precision ground and fitted for maximum performance and minimal deflection
● Heavy duty structure and rigid components for high section modulus ratings
● Reinforced engineered mainframe design proven to outperform competitive models
● Patented by Ercolina simultaneous downfeed and roll movement to minimize deformation
● Programmable touchpad controls with digital center roll positioning display
● Hydraulic machine with memory storage with eight (8) individual programs and unlimited passes
● Remote pendent with low voltage controls and foot pedal switch
● Threaded roll shafts with micrometric flange adjustment helps eliminate spacer usage
● Inline direct drive roll shaft system
● Optional Anti-twist correction system for angle iron “Leg In” applications
● All capacities based on mild grade materials; heavy wall and high tensile materials reduce machine capacity.
OPTIONAL FEATURES:
Ercolina Grease - 1 Can: $38.00
DELIVERY:
SUBJECT TO STOCK
