| Swing Over Bed | 17 inches |
| Swing Over Cross Slide | 10.5 inches |
| Distance Between Centers | 40 inches |
| Spindle Speeds (16) | 20- 1,600 RPM |
| Spindle Nose | D1- 8 |
| Hole Thru Spindle | 3 inches |
| Threads | Inch (38): 2- 72 TPI, Metric (45): 0.4- 14 MM, Feeds (45): 0.002"- 0.016" |
| Cross Slide Travel | 12 inches |
| Tailstock Quill Taper | #5 MT |
| Tailstock Quill Travel | 7 inches |
| Dimensions (L x W x H) | 138" x 42" x 52" |
| Weight | 7000 pounds |
| Electric Req | 480v/3ph |
